4-Channel RS-485 to PoE Ethernet Gateway
PoE 48V or external 9–36V DC · 4× RS-485 independent
SKU: VK-GW-RS485-4CH
4-channel RS-485 to Ethernet converter with PoE power input. Bridges Modbus RTU devices to TCP/IP networks over a single cable.
Quick Specs
| Power | PoE 48V or external 9–36V DC |
| Channels | 4× RS-485 independent |
| Ethernet | 10/100 Mbps with PoE (802.3af) |
| Mounting | DIN-rail or wall-mount |
| Protocol | Modbus RTU ↔ Modbus TCP transparent |
| Baud Rate | 300–921600 bps configurable |
| Dimensions | 112 × 64 × 24mm |
| Protection | ESD ±15kV, surge protection |
| Configuration | Web interface (HTTP) |
| Devices per Channel | Up to 32 Modbus nodes |
Product Description
Industrial-grade protocol converter that bridges up to 4 independent RS-485 serial buses to Ethernet (TCP/IP). Powered via PoE (IEEE 802.3af), eliminating the need for a separate power supply.
Supports Modbus RTU to Modbus TCP transparent conversion, making it ideal for connecting legacy serial instruments, PLCs, sensors, and actuators to modern IP networks.
Key features:
• 4 independent RS-485 channels with individual baud rate settings
• PoE powered — single cable for data and power
• DIN-rail mountable for panel installations
• Web-based configuration interface
• Supports up to 32 Modbus devices per channel
• Baud rates from 300 to 921600 bps
